NEC LED-E018i
1.8 mm Indoor FinePitch LED Module
| Pixel Pitch [mm] | 1.8 |
| Brightness [cd/m²] | 800 |
| Aspect Ratio | 16:9 |
| Order Code | 81000222 |
- DISPLAY
-
Pixel Configuration 3-in-1 SMD (Black) LED type SMD (1415) Aspect Ratio 16:9 Pixel Pitch [mm] 1.8 Brightness (max.) [cd/m²] 800 Lifetime 100000 hrs (50% brightness) Contrast Ratio (typ.) 5000:1 Viewing Angle [°] 140 horizontal / 140 vertical Dimming Capability 256 levels Colour Processing 16 bit Colours [Trill.] 281 LED Driving Method 1/60 dynamic scan Frame Rate [Hz] 50/60 Refresh Rate [Hz] ≤ 3840 Colour Temperature [K] 3000 - 9500 - SCREEN RESOLUTION
-
Resolution per m² 284444 Number of Pixel per module [dot] 320 x 180 Number of Pixel per card [dot] 80 x 180 - ELECTRICAL
-
Power Consumption typ. [W] 212 per m² (normal use) Power Consumption max. [W] 617 per m² - ENVIRONMENTAL CONDITIONS
-
Operating Temperature [°C] -20 to 40 Operating Humidity [%] 10 to 80 - MECHANICAL
-
Dimensions (W x H x D) [mm] per module 600 x 337.5 x 29 Weight [kg] 4.7 - ADDITIONAL FEATURES
-
Shipping Content LED Modules (1 Cabinets, 4 Pixel Cards); Spare Parts Kit Special Characteristics Flush Surface SMD Design; Single Data Receiving Cards; Single Power Supplies Manufacturer NEC Serviceability Front Service IP Level IP20 Certifications CE; ETL; FCC Class A; RoHS Warranty 2 years Material Aluminum Cabinet
