Datasheet
Professional performance, affordable value
The entry point for professional display solutions, the Sharp MultiSync® E9 Series is designed for modern business environments that need more than a consumer TV can offer. Combining essential features for meeting rooms and digital signage with commercial-grade reliability, the E9 Series delivers crisp UHD resolution, integrated media playback, and 16/7 operation at an accessible price point. A professional matte high-haze panel ensures superior visual performance in this product category, minimising reflections and glare common with glossy panels.
Designed for seamless integration across the wider Sharp display family, the E9 Series shares the same core identity, including the same remote control and device management for a consistent user experience. A robust metal back cover secures product longevity in commercial settings. Whether for presentations, retail signage, or corporate communication, the E9 Series gives you the professional edge without stretching your budget
Benefits
- Unhindered readability – a high-haze panel reduces glare from windows and ambient light, keeping signage content and presentations clear for uninterrupted viewing in any environment
- Standardised functionality – shares a common identity with the wider Sharp display portfolio, ensuring unified operation and remote device management, and consistent styling for a seamless user experience.
- Effortless plug-and-play signage – the integrated USB MediaPlayer enables native UHD content playback with auto-start functionality, delivering instant digital signage without the need for external hardware or content management systems.
- Flexible orientation – designed for both portrait and landscape installation, with uniform bezel width on all sides to ensure a clean, professional look in any configuration.
Product Information
Product Name
Sharp MultiSync® E509
Product Group
LCD 50" Essential Large Format Display
Order Code
60006182
Display
Panel Technology
VA with Direct LED backlights
Active Screen Area (W x H) [mm]
1,096 x 616
Screen Size [inch/cm]
50 / 125.7
Aspect Ratio
16:9
Pixel Pitch [mm]
0.285
Brightness [cd/m²]
350
Contrast Ratio (typ.)
4000:1
Viewing Angle [°]
178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Colour Depth [bn]
1.07 (8bit + FRC)
Response Time (typ.) [ms]
8
Panel Refresh Rate [Hz]
60
Haze Level [%]
Pro (25)
Supported Orientation
Landscape; Portrait
Resolution
Native Resolution
3840 x 2160
Supported Resolutions
1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1280 x 960; 1360 x 768; 1400 x 1050; 1440 x 900; 1680 x 1050; 1920 x 1080; 1920 x 1200; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 400; 720 x 480; 720 x 576
Synchronisation Rate
Horizontal Frequency [kHz]
31.5 - 135
Vertical Frequency [Hz]
24 - 75
Connectivity
Input Video Digital
1 x USB-C (with HDCP, 15 W); 2 x HDMI
Input Audio Digital
1x USB-C; 2 x HDMI
Input Control
1 x LAN 100Mbit; 1 x RS232
Input Data
1 x USB 2.0 (MediaPlayer); 1 x USB Typ-C (5V/3A, power for external devices)
Output Audio Analogue
1 x 3,5 mm jack
Remote Control
Remote Control IR; RS-232C (9-pin D-sub) Input
Connectivity
HDMI IN 1
Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; ARC; CEC
HDMI IN 2
Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; CEC
USB-A 1
USB (2.0); 4.5 W; Peripherals; USB Storage
USB-C 1
Video Input; UHD (60 Hz); DP alt. 1.2; HDCP (2.2); Audio Input; USB 2.0; 15 W
Audio Output (3.5 mm)
Audio Output; Line Out
LAN 1
100 MBit/s
RS-232C
9600 bps
Electrical
Power Consumption [W]
99 shipping
Power Savings Mode [W]
< 0.5; < 2 (Networked Standby)
Power Supply
100-240 V AC; 50/60 Hz; internal
Environmental Conditions
Operating Temperature [°C]
+0 to +40
Operating Humidity [%]
20 to 80
Storage Humidity [%]
10 to 80
Storage Temperature [°C]
-20 to +60
Mechanical
Dimensions (W x H x D) [mm]
1,120 x 641 x 59.9
Weight [kg]
9.2
Bezel Width [mm]
10.8
VESA Mounting [mm]
200 x 200 (FDMI); 4 holes; M6
Packaging Dimensions (W x H x D) [mm]
1,253 x 761 x 128
Packaging Weight [kg]
13
MediaPlayer
Supported File Storage / File System
USB 2.0 / FAT16, FAT32
Supported Image Formats
JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640
Supported Video Formats
MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); audio: LPCM, MP3, AAC; WMV (video H.264, Windows Media Video 9, max res 1080p@30Hz, audio WMA 9, WMA 10 Pro)
Supported Audio Formats
MP3 (MP3); max. bit-rate 320 kBit/s
Available Options
Accessories
Feet (ST-43M); Trolley (PD04 Tipster); USB-C cable (USB-C 5M, USB-C 7M); Wall mount (PDW S 32-65 L, PDW S 32-65 P)
Regulatory
Safety and Ergonomics
CE; Energy Star 8; FCC Class B; RCM; UKCA; UL/C-UL or CSA; VCCI
Green Features
Energy Efficiency
Energy consumption: 90 kWh/1000 h; Energy efficiency class: G; LED backlight
Ecological Standards
EnergyStar 8.0
Additional Features
Special Characteristics
CEC Support; HDMI ARC; NaViSet Administrator 2 - free download; Powered USB-Port; Scheduler; USB Media Player
Colour Versions
Black Front Bezel, Black Back Cabinet
Audio
Integrated Speakers (10 W + 10 W)
Shipping Content
2x AAA batteries; Cable Clamps; Display; Power Cable; Remote Control; Setup Manual
Warranty
3 years warranty incl. backlight
Operating Hours
16/7
Remote Management
NaViSet Administrator 2
FCC Class B
CE
RCM
VCCI
